Features
Application
Suitable for communication systems 33ohm, 50oh, 75ohm RF cable, and upt/stp 100ohm, 120ohm 150ohm cable, and HFI260 Armored Fiber Oifer cable
| Dimension | similar to RG174（OD：2.2mm）, RG178（OD：1.5mm) or others |
| Conductor | Silver Plated Alloy Copper 7×0.1mm |
| Dielectric | HFI260 |
| Insulation | teflon,peek,and others |
| Coating | Carbon |
| Inner Screen | Braided screen of silver plated copper wire 95% |
| Inner Jacket | teflon,peek,and others |
| Outer Screen | Braided screen of silver plated copper wire 95% |
| Jacket | teflon,peek,and others |
| OD | 2.4mm |
| Frequency | Up to 200 MHz |
| Conductor to Inner Screen | ＜90pF/m |
| Inner Screenr to Outer Screen | ＜200pF/m |
Military Specification Styles A range of PTFE Insulated wires, designed, manufactured and fully released to meet the requirements of MIL-W-16878 (NEMA HP4) TELFON UL/CSA Approved Styles A range of TEFLON Insulated wires designed are manufactured and fully released to meet the requirements.
Details
CITCABLE Special Insulated wire is available by custom; we can extrude this material in round, square. We can also provide all special insulated wire in stranded and other wire.
